ASME SA 516 GR.70N NACE MR 0103-0175 PLATES

  • Home
  • ASME SA 516 GR.70N NACE MR 0103-0175 PLATES

ASME SA 516 GR.70N NACE MR 0103-0175 PLATES

Renam Alloys Inc. is a prominent manufacturer of SA 516 GR.70N with NACE MR 0103/0175 Plates. As part of this initiative, we have established a state-of-the-art manufacturing facility in India to produce both seamless and welded plates, ensuring their availability worldwide.


Renam Alloys Inc. is a leading supplier of ASME SA516 GR.70N NACE MR-0175 Pressure Vessel Plates. We offer SA516 Grade 70N HIC resistant steel plates, available in various grades and specifications, ensuring their availability for industrial and boiler applications. As trusted stockists in Mumbai, India, we specialize in A516 Grade 70N HIC NACE tested plates and ASTM A516 GR.70N NACE+HIC boiler quality steel plates.

Our A516 Grade 70N Carbon Steel NACE and HIC tested plates meet the rigorous standards required for high-pressure vessel and boiler applications. These SA516 GR.70N industrial (NACE+HIC) boiler and pressure vessel steel plates are available in various configurations, including NACE MR-0103 and NACE MR 0175 pressure vessel steel plates, ensuring durability and corrosion resistance.

Quality Assurance

The quality assurance processes are meticulously planned according to the client’s specific requirements and the necessary specifications. These are then translated into detailed instructions, with audits performed during manufacturing and inspection. The inspection stages and critical check points are determined to facilitate in-process inspections and document significant testing stages. Various heat treatments are applied during production to ensure the plates are strengthened, durable, and resistant to pitting and decay. The key attributes that make these plates highly desirable include their tensile strength, corrosion resistance, and toughness.


Packaging

Once the plates have undergone the necessary heat treatments, which enhance their strength and resistance to corrosion and pitting, the packaging phase becomes critical. Proper packaging ensures the protection of the plates during transit and helps maintain their quality for an extended period. The plates are typically packed in wooden boxes, crates, and cases, or sometimes in spiral wound paper tubes. They are carefully wrapped with stretch film and placed on pallets to ensure secure delivery.


PEOPLE ALSO SEARCHED FOR A516 GR.70N HIC NACE TESTED PLATES

Keywords frequently searched for in relation to these plates include sa516 nace steel plate, astm a516 grade 70n nace mr0103 hic tested steel plates, sa516 grade 70n nace + hic pressure vessel steel plates price list, sa 516 nace pressure vessel gr.70n steel plate stockists in india, and others. These terms indicate a growing interest in high-quality and tested pressure vessel steel plates for various applications.


Specifications

Grade ASME SA 516 GR.70N Boiler and Pressure Vessel Steel Plates
Width 1000mm-4500mm
Thickness 5mm-150mm
Length 3000mm-18000mm
Supply Condition As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested 52° C
Tempering Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service.
Process of Manufacturing Hot-Rolled (HR)

CHEMICAL COMPOSITION OF A516 BQ GR.70N NACE AND HIC STEEL PLATES

C Si Mn P S Al Cr Cu Ni Mo Nb Ti V
0.18 0.4 0.95/1.50 0.015 0.008 0.02 (Min) 0.3 0.3 0.3 0.08 0.01 0.03 0.02

MECHANICAL PROPERTIES OF NACE MR-0175 RESISTANT STEEL PLATES

Tensile strength (ksi) Yield strength (ksi) Elongation min, % 200 mm (8 in) Elongation min, % 50 mm (2 in)
485-620 (70-90) 260 (38) 17 21

EQUIVALENT GRADE OF A516 GR.70N NACE MR-0175/0103 BOILER PLATES

British Standard European Norm ASTM/ASME DIN
BS1501-224-490A/B EN10028 P355GH A/SA516 - Grade 70 -

WE OFFERS FOLLOWING PROCESSING FOR ASTM A516 HOT ROLLED BOILER GR.70N NACE RESISTANT STEEL PLATE

Cutting, Forming Drilling / Machining, Grinding, Testing


Applications of ASTM A516 NACE + HIC Hot Rolled Pressure Vessel Grade 70N Steel Plates

The ASTM A516 NACE + HIC Hot Rolled Pressure Vessel Grade 70N Steel Plates find extensive use across a wide range of industries. These applications include machine building, pylons and other architectural structures, lifting and mobile equipment, and the construction of bridges. They are also used in wearing plates, framework structures, crane booms, and rail cars. Additionally, these plates are applied in stone or iron chutes, truck frames, containers, vehicles and transport equipment, and steel constructions. Furthermore, they serve as anti-drill plates for security doors, shot blasting equipment, and tumbling machines.
