ASME SA 516 GR.60N NACE AND MR 0103-0175 PLATES

  • Home
  • ASME SA 516 GR.60N NACE AND MR 0103-0175 PLATES

ASME SA 516 GR.60N NACE AND MR 0103-0175 PLATES

Renam Alloys Inc. SA 516 GR.60N WITH NACE MR 0103/0175 PLATES meet the standard requirements for pressure vessel plates, carbon steel designed for both moderate and low-temperature applications. These plates and pressure vessel plates are commonly used in environments requiring resistance to NACE MR 0103/0175 standards, including NACE and HIC plates. It is one of the most widely recognized and preferred steel grades for manufacturing steel plates. This grade is specifically designed for pressure vessels where high hardness is essential. It is highly regarded due to its exceptional tensile strength and oxidation resistance. Renam Alloys Inc. maintains a large inventory of raw materials in various sizes, grades, and cuts, ensuring readiness for any project needs.


Renam Alloys Inc. is a leading supplier of SA516 Steel NACE MR0103 Plates, A516 Grade 60N HIC NACE Tested Plates, and ASME SA516 GR.60N NACE MR-0175 Pressure Vessel Plates. We also offer ASTM A516 GR.60N NACE+HIC Boiler Quality Steel Plates as a reliable stockist. Our range includes SA516 Grade 60N HIC Resistant Steel Plates for various industrial applications, and we are a prominent SA516 Grade 60N BQ Plates Stockist in Mumbai, India.

We provide A516 Grade 60N Carbon Steel NACE and HIC Tested Plates, ensuring high performance for pressure vessel applications. Our NACE MR-0103 Pressure Vessel A516 GR.60N Steel Plates are designed for optimal durability and resistance. Additionally, we offer SA516 GR.60N Industrial (NACE+HIC) Boiler and Pressure Vessel Steel Plates with superior qualities for demanding industrial environments. Renam Alloys Inc. is your trusted source for SA 516 GR.60N NACE MR 0103 Plates, SA 516 GR.60N NACE MR 0175 Plates, and A516 Hot Rolled NACE MR-0175 Pressure Vessel Grade 60N Steel Plates that meet international standards. We are also a reliable Supplier and Exporter.

Features

The SA 516 GR.60N with NACE MR 0103/0175 Plates are available in various shapes and sizes, customized according to customer requirements. These plates are renowned for their high tensile strength, corrosion resistance, and ability to withstand pitting and decay. Their remarkable properties make them suitable for diverse applications across different temperatures. Manufactured using premium raw materials, these plates undergo rigorous testing and inspection before being used in production.


Testing

To ensure the durability and toughness of the SA 516 GR.60N with NACE MR 0103/0175 Plates, various tests are performed, including the ultrasonic test in accordance with customer specifications, MTC test, and Charpy impact test. These plates are produced to meet both national and international quality standards, covering a range of grades.


Certificate

Certification and packaging are crucial to verifying the durability and quality of the plates. These plates undergo several tests and inspections, including destructive testing, hardness testing, and third-party inspection. Manufacturers provide essential certificates such as the IBR test certificate, Tested Fine Grained Pressure Vessel Steel Saucers Sour Gas Service, and third-party test reports. Additionally, raw material test certificates are issued to ensure the highest standards.


Packaging

When it comes to packaging the SA 516 GR.60N with NACE MR 0103/0175 Plates, they are individually packed in waterproof material and bundled with nylon rope. A clear label on the package provides details such as the yield name, size, length, and specifications. These plates are carefully packed following international standards, especially during export to other countries. You can purchase these plates online at competitive prices.


People Also Searched For

Customers often search for related products such as SA 516 GR.60N HIC Plates, SA516 NACE Steel Plate, ASTM A516 Grade 60N NACE MR0103 HIC Tested Steel Plates, and more. Additionally, you can find details on ASME SA516 GR.60N HIC Pressure Vessel Plates, A516 Grade 60N NACE MR0175 Boiler Quality Plates, and other specifications related to NACE and HIC tested steel plates. Renam Alloys Inc. offers comprehensive information and products for industrial and boiler quality applications.


Specifications

Grade ASME SA 516 GR.60N Boiler and Pressure Vessel Steel Plates
Width 1000mm-4500mm
Thickness 5mm-150mm
Length 3000mm-18000mm
Supply Condition As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested 52° C
Tempering Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service.
Process of Manufacturing Hot-Rolled (HR)

CHEMICAL COMPOSITION OF A516 BQ GR.60N NACE AND HIC STEEL PLATES

C Si Mn P S Al Cr Cu Ni Mo Nb Ti V
0.20 0.4 0.95/1.50 0.025 0.025 0.02 0.3 0.3 0.3 0.08 0.01 0.03 0.02

MECHANICAL PROPERTIES OF NACE MR-0175 RESISTANT STEEL PLATES

Tensile strength Yield strength Elongation min, % 200 mm (8 in) Elongation min, % 50 mm (2 in)
415-550 MPa 250 MPa 21 25

EQUIVALENT GRADE OF A516 GR.60N NACE MR-0175/0103 BOILER PLATES

British Standard European Norm ASTM/ASME DIN
BS1501-161-430A EN10028 P265GH A/SA516 - Grade 60 DIN 17155 HII

WE OFFERS FOLLOWING PROCESSING FOR ASTM A516 HOT ROLLED BOILER GR.60N NACE RESISTANT STEEL PLATE

Cutting, Forming Drilling / Machining, Grinding, Testing


Applications of ASTM A516 NACE + HIC Hot Rolled Pressure Vessel Grade 60N Steel Plates

The ASTM A516 NACE + HIC Hot Rolled Pressure Vessel Grade 60N Steel Plates are used in a variety of applications, including machine building, construction of pylons and other architectural structures, and lifting and mobile equipment. These plates are also widely utilized in the construction of bridges, wearing plates, and framework structures. Other notable uses include crane booms, rail cars, stone or iron chutes, truck frames, containers, and vehicles and transport equipment. Additionally, they are employed in steel constructions and anti-drill plates such as security doors, shot blasting equipment, and tumbling machines.
